Using advanced technology, the standing seam method makes it easy and quick to install titanium zinc to a building’s facade. Instead of manually folding the material, prepared bays and automatic seam folding are used. These premade bays come in customized sizes and can be folded on-site either by machine or by hand.
Not only can straight sections be created, but it’s also simple to make curved (convex and concave) and tapering sections. The bays are secured to the structure using both permanent and sliding clips.
To form the standing seam façade with a thickness of 0.80 mm, the zinc bays are joined together longitudinally. The allowed bay width is determined by factors such as wind load and façade height. If the bay is horizontal, it’s recommended to keep the length around 5 meters for easier handling, with a width between 300 and 430 mm for optimal work. For vertical installations, it’s advised to limit the length and width of standing seam bays to 6 meters and 500 mm, respectively, for handling purposes. At the top, a single clip holds the sheets securely in place.
The standing seam system enables the quick and cost-effective installation of zinc roofs or façades with titanium zinc. Preformed bays, available in custom sizes, facilitate a speedy assembly process, and mechanical folding minimizes manual labour, contributing to overall cost savings.
The system allows for the creation of diverse designs, including straight, curved (convex and concave), and tapering bays. This versatility in design is achieved without compromising quality or increasing complexity, providing architects and builders with creative freedom.
By utilizing standing seams and sealing tape between the seams, the system promotes superior rainproofing, ensuring protection against moisture infiltration. This feature is particularly beneficial for maintaining the longevity and structural integrity of buildings, especially in areas prone to heavy rainfall or harsh weather conditions.
The use of high-quality materials and secure fastening techniques, such as fixed and sliding clips, contributes to the long-term durability of the standing seam system. Proper support provided by unplaned wooden boards further enhances the stability and resilience of the facade, ensuring its structural integrity over time.
The standing seam system can be tailored to specific site conditions and architectural preferences, offering options for both horizontal and vertical installations. Additionally, the system accommodates different bay widths and lengths, allowing for optimal configuration based on factors such as wind load and facade height, thereby maximizing efficiency and performance.
Single Lock Standing Seam System Wall Horizontal Vertical Section
Single Lock Standing Seam System Wall Horizontal System Profile
Single Lock Standing Seam System Wall Horizontal Standing Seam Clips
Single Lock Standing Seam System Wall Horizontal Sill Flashing Window
Single Lock Standing Seam System Wall Horizontal Outer Corner
Single Lock Standing Seam System Wall Horizontal Outer Corner Alternative
Single Lock Standing Seam System Wall Horizontal Junction Panels
Single Lock Standing Seam System Wall Horizontal Jamb Flashing Window Right
Single Lock Standing Seam System Wall Horizontal Jamb Flashing Window Left
Single Lock Standing Seam System Wall Horizontal Inner Corner
Single Lock Standing Seam System Wall Horizontal Horizontal Section
Single Lock Standing Seam System Wall Horizontal Head Flashing Window
Single Lock Standing Seam System Wall Horizontal Head Capping
Single Lock Standing Seam System Wall Horizontal Eaves Flashing Wall
Single Lock Standing Seam System Wall Horizontal Eaves Flashing Detail
Single Lock Standing Seam System Wall Horizontal Clip Application and Layout
Single Lock Standing Seam System Wall Horizontal Abutment Right
Single Lock Standing Seam System Wall Horizontal Abutment Left
Single Lock Standing Seam System Wall Vertical Vertical Section
Single Lock Standing Seam System Wall Vertical System Profile
Single Lock Standing Seam System Wall Vertical Standing Seam Clips
Single Lock Standing Seam System Wall Vertical Sill Flashing Window
Single Lock Standing Seam System Wall Vertical Outer Corner
Single Lock Standing Seam System Wall Vertical Junction Panels
Single Lock Standing Seam System Wall Vertical Jamb Flashing Window Right
Single Lock Standing Seam System Wall Vertical Jamb Flashing Window Left
Single Lock Standing Seam System Wall Vertical Inner Corner
Single Lock Standing Seam System Wall Vertical Horizontal Section
Single Lock Standing Seam System Wall Vertical Head Flashing Window
Single Lock Standing Seam System Wall Vertical Head Capping
Single Lock Standing Seam System Wall Vertical Eaves Flashing Detail
Single Lock Standing Seam System Wall Vertical Clip Application and Layout
Single Lock Standing Seam System Wall Vertical Abutment Right
Single Lock Standing Seam System Wall Vertical Abutment Left
Single Lock Standing Seam System Wall Vertical Eaves Flashing Wall
